Mikrotik 915_Omni_antenna 915 Omni antenna

Description

MikroTik 915 Omni Antenna is a high-performance antenna designed for LoRa® applications operating in the 900–928 MHz frequency range. It provides a 6.5 dBi gain at 868 MHz and 4.5 dBi at 915 MHz, ensuring robust signal coverage for IoT deployments in regions like the U.S., Brazil, Australia, and New Zealand. The antenna features a 360° horizontal beamwidth and a 30° vertical beamwidth, making it ideal for point-to-multi-point wireless networks, community IoT projects, and outdoor wireless broadcasting.

Key Features:

• Frequency Range: 900 – 928 MHz
• Gain: 6.5 dBi (868 MHz) / 4.5 dBi (915 MHz)
• Horizontal Beamwidth: 360°
• Vertical Beamwidth: 30°
• Nominal Impedance: 50 Ω
• Lightning Protection: DC Ground
• Connector: SMA Female
• Weight: 0.6 kg
• Dimensions: 42 x 68 x 495 mm
• Ingress Protection: IP66 (dust-tight and high-pressure water-resistant)
• Included Accessories: 1m SMA cable, mounting bracket

For more information or to purchase, visit our product page. For support, refer to the MikroTik 915 Omni Antenna User Manual.
